產品介紹
森尼克SCB-CAS/CASR/CKSR系列：SCB-15CAS, SCB-25CAS,SCB-50CAS，SCB-15CASR, SCB-25CASR,SCB-50CASR，SCB-15CKSR, SCB-25CKSR,SCB-50CKSR,SCB-75CKSR國產Pin To Pin替代如下型號：LEM萊姆CASR/CAS/CKSR系列 ：CAS 6-NP，CAS 15-NP，CAS 25-NP ，CAS 50-NP ，CASR 6-NP，CASR 15-NP，CASR 25-NP，CASR 50-NP，CKSR 6-NP，CKSR 15-NP，CKSR 25-NP，CKSR 50-NP
For the electronic measurement of current: DC, AC, pulsed…,with galvanic separation between the primary and the secondary circuit.
Features
● Closed loop (compensated) multi-range
current transducer
● Voltage output
● Single supply
● Compact design for PCB mounting.
Special feature
● Dedicated 5 primary conductors configuration.
Advantages
● Very low temperature coefficient of offset
● Very good dv/tdimmunity
● Reduced height
● Reference pin with two modes: Ref IN and Ref OUT
● Extended measuring range for unipolar measurement.
Applications
● AC variable speed and servo motor drives
● Static converters for DC motor drives
● Battery supplied applications
● Uninterruptible Power Supplies (UPS)
● Switched Mode Power Supplies (SMPS)
● Power supplies for welding applications
● Solar inverters.
Standards
● IEC 60950-1: 2006
● IEC 61010-1: 2010
● IEC 61326-1: 2012
● UL 508: 2010.
Application Domain
● Industrial
我司是森尼克正式授權代理商，可以提供技術支持，需要技術資料與樣品可以向我司業務人員索取（13923795851孫生-微信同號）；
